Highlights
- Baader T-Ring to connect Canon EOS DSLR cameras on the Astro T-2 system
- Represents the standard exact distance of 55.0mm from the front support surface of the T-ring to the image plane of the camera body forth
- On the camera side: Canon EOS Bayonet
- Telescope side: T-2 internal thread with 0.75mm pitch
Specifications
| Manufacturer | Baader Planetarium |
|---|---|
| SKU (#) | 2408319 |
| EAN Code | 4047825012562 |
| Weight (NETTO) | 0.056 |
| Optical length (mm) | 11 |
| Usage | to connect (D)SLR cameras to the Astro T-2 thread system |
| Camera Adaptable | Canon EOS EF |
| Inner Diameter / Clear Aperture (mm) | 41 |
| Outer Diameter | 64 |
| Inner Connection (lens sided) | Thread, T-2 (M42 x 0,75) |
| Outer Connection (eyepiece/-camera-sided) | Bayonet |
| Compatible Brands | Astro T-2, Baader Planetarium |
| Type of Adapter | Camera Adapter |
